Holzstar KGZ 305 E Double Bevel Mitre Saw 210mm Diameter Blade 230volt

Holzstar KGZ 305 E Double Bevel Mitre Saw 210mm Diameter Blade 230volt

• Infinitely adjustable double mitre and tilt to the left
• Base plate and rotary table made of die-cast aluminium, at the same time compact, robust and easily transportable
• Laser projection on the workpiece for precise control of the cutting position
• Laterally extendable support aids for longer workpieces
• Double adjustable cross-cut depth limiter
• Pull function for extended cutting range
• Standard with hold-down clamp for safe workpiece locking
• Extraction connection for dust collection bag or connection of an external extraction system

• 5702305

TECHNICAL DATA

General Features
Saw band speed 4500min¯¹
Saw blade diameter 210mm
Sound pressure level 93.6dB(A)
Sound power level 106.6dB(A)
Vibration emission value 4.58m/s²
Extraction duct outside nominal width 32.5mm
Max. bevel angle range left 45°
Max. mitre left 45°
Max. mitre right 45°
Dimensions and weights
Length (product) approx. 650mm
Width/depth (product) approx. 450mm
Height (product) approx. 430mm
Net weight approx. 10.5kg
Electrical Data
Supply voltage 230V
Mains frequency 50Hz
Drive motor output 1,5kW
Cutting capacity
Cutting capacity at 0° inclination / 0° mitre 220 x 70mm
Cutting capacity at -45° inclination / 0° mitre 155 x 70mm
Cutting capacity at 0° inclination / -45° mitre 220 x 35mm
Cutting capacity at -45° inclination / -45° mitre 155 x 35mm
